Mass Flow Control: Turndown 100:1, Auto N2 Purge
Electrolyte Circulation (PEM):
– DI Water Temperature Control(RT ~ 95°C), DI Water Level Control & Alarm, Auto Fill
– Water Conductivity Monitoring, DI Water & Gas Seperation
– DI Water Flow Control, Water Filtering(Micro & ion)
Electrolyte Circulation (ALK, AEM):
– Liquid Temperature Control(RT ~ 95°C), Liquid Level Control & Alarm, Auto Fill(Option)
– Liquid & Gas Seperation
– Liquid Flow Control
Gas Colling: Gas cooling and Trap (Condensation water and gas split)
Concentration Sensor: H2 in O2, O2 in H2 (0-5%, 10% Vol)
Back Pressure Control: Max 10bar (30Bar – option)
Cell voltage monitoring: Nominated Channel, ±5V/Ch

Options
– Integrated AC impedance measurement system (10mHz ~ 10kHz)
